Regenerative braking is used in vehicles that make use of electric motors, primarily fully electric vehicles and hybrid electric vehicles. One of the more interesting properties of an electric motor is that, when it's run in one direction, it converts electrical energy into mechanical energy that can be used to perform work (such as turning the wheels of a car), but when the motor is run in the opposite direction, a properly designed motor becomes an electric generator, converting mechanical energy into electrical energy. This electrical energy can then be fed into a charging system for the car's batteries.

In a regenerative braking system, the trick to getting the motor to run backwards is to use the vehicle's momentum as the mechanical energy that puts the motor into reverse. Momentum is the property that keeps the vehicle moving forward once it's been brought up to speed. Once the motor has been reversed, the electricity generated by the motor is fed back into the batteries, where it can be used to accelerate the car again after it stops. Sophisticated electronic circuitry is necessary to decide when the motor should reverse, while specialized electric circuits route the electricity generated by the motor into the vehicle's batteries. In some cases, the energy produced by these types of brakes is stored in a series of capacitors for later use.

There's a general movement in the automotive industry toward so-called brake-by-wire systems where many of the functions of brakes that have traditionally been performed mechanically will be performed electronically. Hybrids and electric cars will probably be early adopters of these brake types. At present, different automotive engineers have come up with differing circuit designs to handle the complexities of regenerative braking; however, in all cases, the single most important part of the braking circuitry is the braking controller, which we'll discuss in the next section.
